China 90 Degrees Male Panel Mount Pcb Waterproof Connector M12 8 Pin wholesale

90 Degrees Male Panel Mount Pcb Waterproof Connector M12 8 Pin

Name: 90 Degrees Male Panel Mount Pcb Waterproof Connector M12 8 Pin
Brand: RIGOAL
Price: 1 USD

Ask Latest Price

Video Channel

Brand Name :RIGOAL

Model Number :m12 waterproof connector

Certification :CE，ROHS，ISO

Place of Origin :Shen zhen，China

MOQ :100

Price :negotiable

Payment Terms :T/T, Western Union, MoneyGram

Supply Ability :100000

Delivery Time :7~14

Packaging Details :1.Our packaging:each pcs in one PE bag, then put in a small carton. 2.According to customer request.

Pins :4p, 5P, 12p, 8P

Protection degree :IP67/ip68

Standard :IEC 61076-2-112

Connector contacts :Brass with gold plated

Connection type :Panel mount/Cable type

Operating voltage :250V-AC/ 60V/ 30V, current 4A / 1.5A

Product name :Circular Connector M12 Male and Female 3, 4, 5, 8 Pin

Gender :male/female

Contact Now

Add to Cart

View Product Description

M12 8pin 90 Degrees Panel Mount Pcb Waterproof Connector

Product Description

Product Name:
 replaced Phoenix Binder M12 90 degree angled PCB female and male panel mount connector
 model number:M12-R-S

 series:M12 Connector
 Core number:2,3,4(A/B/D),5(A/B),6,8(A/X),12,17Core
 Authentication:CE,RoHS
 waterproof:IP67/IP68

Advantages :

· Operating voltage 60V / 30V, rated current 3A / 1A.
 · 3 , 4 , 5 (B-Coding) , 6 , 8 ,12 , 17 poles are available. · Protection degree IP67. · Temperature range: -40℃~+105℃. · Cable
 length 1m , 2m , 3m or upon customized specification. · UL94-VO flame retardant degree.
Alternative mount arrangements for solder cup or PCB Panel Mount and distribution version available Available as a loose piece or
 as a pre-made M12 cables
